椿本产品选择

塑料系列桥式TKP型、TKP型MW规格、TKP型长跨距规格、TKP型旋转规格

链节
缩短、延长

标准电缆拖链，尺寸范围从小到大。
·它是最常用且易于使用的。
长跨距规格、旋转规格以及其他各种特殊规格。
·MW规格利用滑动性高的材料，具有防止电缆软管外膜磨损的效果。

特性

TKP型

丰富的尺寸

从小尺寸到大尺寸共16种。
塑料，轻便，经济实惠
易于拼接

将插针插入孔中的简单连接结构，便于切断和连接。
支持多层隔断

TKP35H22至TKP125H74 (部分尺寸除外) 可将收纳空间分成多个部分，提高布局的自由度。
钢制的固定件也可以变更为不锈钢制。
在保持品质的基础上，增加了对环境的考虑

TKP形的部分尺寸改用环保再生材料，在保持与以往相同的性能、尺寸、外观的同时，
实现更环保的产品制造。

TKP型MW规格

低尘

与 TKP 型相比，电缆拖链和电缆/软管滑动产生的磨损粉较少，电缆拖链连接部件滑动产生的磨损粉也较少。
近似尺寸和结构与TKP型相同

特殊规格

TKP型长跨距规格

这是一种使用方法，当需要超过效率曲线图上自由跨距的长行程时，电缆拖链会在导轨上滑动。
- 通过安装滑橇，可实现长行程和高速运动，从而延长使用寿命并节省人工。

通过降低运行成本，为降低总成本和环境负荷做贡献。

TKP型旋转规格

·可用于旋转运动的设备。
·不能使用标准品。是特殊制作品。

查看详细规格

关于其他的特殊规格请参照这里。

产品目录、使用说明书

商品一览表

※单击以查看详细信息。全部开启全部关闭

缆线软管最大外径4mm、7mm、8mm (TKP13~，TKP17~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
4	13	10	6	20	TKP13H10-20W6R20	TKP13H10-30W6R20	---	---	---	---	---	---	---
28	TKP13H10-20W6R28	TKP13H10-30W6R28
37	TKP13H10-20W6R37	TKP13H10-30W6R37
7	17	11	10	17	---	TKP17H11-30W10R17	---	---	---	---	---	---	---
8	13	10	10	18	---	TKP13H10-30W10R18TC	TKP13H10-30W10R18M	---	---	---	---	---	---
20	TKP13H10-20W10R20	---	---
28	TKP13H10-20W10R28	TKP13H10-30W10R28TC	TKP13H10-30W10R28M
37	TKP13H10-20W10R37	TKP13H10-30W10R37TC	TKP13H10-30W10R37M
15	20	TKP13H10-20W15R20	TKP13H10-30W15R20	---	---	---	---	---	---	---
28	TKP13H10-20W15R28	TKP13H10-30W15R28
37	TKP13H10-20W15R37	TKP13H10-30W15R37
20	18	---	TKP13H10-30W20R18TC	TKP13H10-30W20R18M	---	---	---	---	---	---
20	TKP13H10-20W20R20	---	---
28	TKP13H10-20W20R28	TKP13H10-30W20R28TC	TKP13H10-30W20R28M
37	TKP13H10-20W20R37	TKP13H10-30W20R37TC	TKP13H10-30W20R37M

电缆软管最大外径11mm、12mm、13mm、14mm、20mm (TKP18~，TKP25~，TKP35~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
11	35	22	13	37	---	TKP35H22-30W13R37	TKP35H22-30W13R37M	---	TKP35H22-40W13R37	TKP35H22-40W13R37M	---	---	---
50	TKP35H22-30W13R50	TKP35H22-30W13R50M	TKP35H22-40W13R50	TKP35H22-40W13R50M
75	TKP35H22-30W13R75	TKP35H22-30W13R75M	TKP35H22-40W13R75	TKP35H22-40W13R75M
100	TKP35H22-30W13R100	TKP35H22-30W13R100M	TKP35H22-40W13R100	TKP35H22-40W13R100M
12	18	14	15	28	---	TKP18H14-30W15R28TC	TKP18H14-30W15R28M	---	---	---	---	---	---
37	TKP18H14-30W15R37TC	TKP18H14-30W15R37M
50	TKP18H14-30W15R50TC	TKP18H14-30W15R50M
40	28	---	TKP18H14-30W40R28TC	TKP18H14-30W40R28M	---	---	---	---	---	---
37	TKP18H14-30W40R37TC	TKP18H14-30W40R37M
50	TKP18H14-30W40R50TC	TKP18H14-30W40R50M
13	15	15	28	TKP18H15-20W15R28	---	---	---	---	---	---	---	---
37	TKP18H15-20W15R37
50	TKP18H15-20W15R50
20	28	TKP18H15-20W20R28	TKP18H15-30W20R28	---	---	---	---	---	---	---
37	TKP18H15-20W20R37	TKP18H15-30W20R37
50	TKP18H15-20W20R50	TKP18H15-30W20R50
30	28	TKP18H15-20W30R28	TKP18H15-30W30R28	---	---	---	---	---	---	---
37	TKP18H15-20W30R37	TKP18H15-30W30R37
50	TKP18H15-20W30R50	TKP18H15-30W30R50
40	28	TKP18H15-20W40R28	---	---	---	---	---	---	---	---
37	TKP18H15-20W40R37
50	TKP18H15-20W40R50
25	15	15	28	---	TKP25H15-30W15R28	TKP25H15-30W15R28M	---	---	---	---	---	---
37	TKP25H15-30W15R37	TKP25H15-30W15R37M
50	TKP25H15-30W15R50	TKP25H15-30W15R50M
20	28	---	TKP25H15-30W20R28	TKP25H15-30W20R28M	---	---	---	---	---	---
37	TKP25H15-30W20R37	TKP25H15-30W20R37M
50	TKP25H15-30W20R50	TKP25H15-30W20R50M
30	28	---	TKP25H15-30W30R28	TKP25H15-30W30R28M	---	---	---	---	---	---
37	TKP25H15-30W30R37	TKP25H15-30W30R37M
50	TKP25H15-30W30R50	TKP25H15-30W30R50M
14	35	32	16	48	---	TKP35H32-30W16R48	---	---	---	---	---	---	---
60	TKP35H32-30W16R60	TKP35H32-30W16R60M
75	TKP35H32-30W16R75	TKP35H32-30W16R75M
100	TKP35H32-30W16R100	TKP35H32-30W16R100M
125	TKP35H32-30W16R125	TKP35H32-30W16R125M
20	35	22	25	37	---	TKP35H22-30W25R37	TKP35H22-30W25R37M	TKP35H22-30W25R37	TKP35H22-40W25R37	TKP35H22-40W25R37M	---	---	---
50	TKP35H22-30W25R50	TKP35H22-30W25R50M	TKP35H22-30W25R50	TKP35H22-40W25R50	TKP35H22-40W25R50M
75	TKP35H22-30W25R75	TKP35H22-30W25R75M	TKP35H22-30W25R75	TKP35H22-40W25R75	TKP35H22-40W25R75M
100	TKP35H22-30W25R100	TKP35H22-30W25R100M	TKP35H22-30W25R100	TKP35H22-40W25R100	TKP35H22-40W25R100M
38	37	---	TKP35H22-30W38R37	TKP35H22-30W38R37M	TKP35H22-30W38R37	TKP35H22-40W38R37	TKP35H22-40W38R37M	---	---	---
50	TKP35H22-30W38R50	TKP35H22-30W38R50M	TKP35H22-30W38R50	TKP35H22-40W38R50	TKP35H22-40W38R50M
75	TKP35H22-30W38R75	TKP35H22-30W38R75M	TKP35H22-30W38R75	TKP35H22-40W38R75	TKP35H22-40W38R75M
100	TKP35H22-30W38R100	TKP35H22-30W38R100M	TKP35H22-30W38R100	TKP35H22-40W38R100	TKP35H22-40W38R100M
50	37	---	TKP35H22-30W50R37	TKP35H22-30W50R37M	TKP35H22-30W50R37	TKP35H22-40W50R37	TKP35H22-40W50R37M	---	---	---
50	TKP35H22-30W50R50	TKP35H22-30W50R50M	TKP35H22-30W50R50	TKP35H22-40W50R50	TKP35H22-40W50R50M
75	TKP35H22-30W50R75	TKP35H22-30W50R75M	TKP35H22-30W50R75	TKP35H22-40W50R75	TKP35H22-40W50R75M
100	TKP35H22-30W50R100	TKP35H22-30W50R100M	TKP35H22-30W50R100	TKP35H22-40W50R100	TKP35H22-40W50R100M
63	37	---	TKP35H22-30W63R37	TKP35H22-30W63R37M	TKP35H22-30W63R37	TKP35H22-40W63R37	TKP35H22-40W63R37M	---	---	---
50	TKP35H22-30W63R50	TKP35H22-30W63R50M	TKP35H22-30W63R50	TKP35H22-40W63R50	TKP35H22-40W63R50M
75	TKP35H22-30W63R75	TKP35H22-30W63R75M	TKP35H22-30W63R75	TKP35H22-40W63R75	TKP35H22-40W63R75M
100	TKP35H22-30W63R100	TKP35H22-30W63R100M	TKP35H22-30W63R100	TKP35H22-40W63R100	TKP35H22-40W63R100M

缆线软管最大外径22mm, 29mm (TKP35~，TKP45~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
22	45	25	38	50	---	TKP45H25-30W38R50	TKP45H25-30W38R50M	TKP45H25-30W38R50	TKP45H25-40W38R50	TKP45H25-40W38R50M	---	---	---
75	TKP45H25-30W38R75	TKP45H25-30W38R75M	TKP45H25-30W38R75	TKP45H25-40W38R75	TKP45H25-40W38R75M
95	TKP45H25-30W38R95	TKP45H25-30W38R95M	TKP45H25-30W38R95	TKP45H25-40W38R95	TKP45H25-40W38R95M
125	TKP45H25-30W38R125	TKP45H25-30W38R125M	TKP45H25-30W38R125	TKP45H25-40W38R125	TKP45H25-40W38R125M
150	TKP45H25-30W38R150	TKP45H25-30W38R150M	TKP45H25-30W38R150	TKP45H25-40W38R150	TKP45H25-40W38R150M
200	TKP45H25-30W38R200	TKP45H25-30W38R200M	TKP45H25-30W38R200	TKP45H25-40W38R200	TKP45H25-40W38R200M
58	50	---	TKP45H25-30W58R50	TKP45H25-30W58R50M	TKP45H25-30W58R50	TKP45H25-40W58R50	TKP45H25-40W58R50M	---	---	---
75	TKP45H25-30W58R75	TKP45H25-30W58R75M	TKP45H25-30W58R75	TKP45H25-40W58R75	TKP45H25-40W58R75M
95	TKP45H25-30W58R95	TKP45H25-30W58R95M	TKP45H25-30W58R95	TKP45H25-40W58R95	TKP45H25-40W58R95M
125	TKP45H25-30W58R125	TKP45H25-30W58R125M	TKP45H25-30W58R125	TKP45H25-40W58R125	TKP45H25-40W58R125M
150	TKP45H25-30W58R150	TKP45H25-30W58R150M	TKP45H25-30W58R150	TKP45H25-40W58R150	TKP45H25-40W58R150M
200	TKP45H25-30W58R200	TKP45H25-30W58R200M	TKP45H25-30W58R200	TKP45H25-40W58R200	TKP45H25-40W58R200M
78	50	---	TKP45H25-30W78R50	TKP45H25-30W78R50M	TKP45H25-30W78R50	TKP45H25-40W78R50	TKP45H25-40W78R50M	---	---	---
75	TKP45H25-30W78R75	TKP45H25-30W78R75M	TKP45H25-30W78R75	TKP45H25-40W78R75	TKP45H25-40W78R75M
95	TKP45H25-30W78R95	TKP45H25-30W78R95M	TKP45H25-30W78R95	TKP45H25-40W78R95	TKP45H25-40W78R95M
125	TKP45H25-30W78R125	TKP45H25-30W78R125M	TKP45H25-30W78R125	TKP45H25-40W78R125	TKP45H25-40W78R125M
150	TKP45H25-30W78R150	TKP45H25-30W78R150M	TKP45H25-30W78R150	TKP45H25-40W78R150	TKP45H25-40W78R150M
200	TKP45H25-30W78R200	TKP45H25-30W78R200M	TKP45H25-30W78R200	TKP45H25-40W78R200	TKP45H25-40W78R200M
103	50	---	TKP45H25-30W103R50	TKP45H25-30W103R50M	TKP45H25-30W103R50	TKP45H25-40W103R50	TKP45H25-40W103R50M	---	---	---
75	TKP45H25-30W103R75	TKP45H25-30W103R75M	TKP45H25-30W103R75	TKP45H25-40W103R75	TKP45H25-40W103R75M
95	TKP45H25-30W103R95	TKP45H25-30W103R95M	TKP45H25-30W103R95	TKP45H25-40W103R95	TKP45H25-40W103R95M
125	TKP45H25-30W103R125	TKP45H25-30W103R125M	TKP45H25-30W103R125	TKP45H25-40W103R125	TKP45H25-40W103R125M
150	TKP45H25-30W103R150	TKP45H25-30W103R150M	TKP45H25-30W103R150	TKP45H25-40W103R150	TKP45H25-40W103R150M
200	TKP45H25-30W103R200	TKP45H25-30W103R200M	TKP45H25-30W103R200	TKP45H25-40W103R200	TKP45H25-40W103R200M
35	32	25	48	---	TKP35H32-30W25R48	---	---	TKP35H32-40W25R48	---	---	---	---
60	TKP35H32-30W25R60	TKP35H32-40W25R60
75	TKP35H32-30W25R75	TKP35H32-40W25R75
100	TKP35H32-30W25R100	TKP35H32-40W25R100
125	TKP35H32-30W25R125	TKP35H32-40W25R125
29	35	32	38	48	---	TKP35H32-30W38R48	---	---	TKP35H32-40W38R48	---	---	---	---
60	TKP35H32-30W38R60	TKP35H32-40W38R60
75	TKP35H32-30W38R75	TKP35H32-40W38R75
100	TKP35H32-30W38R100	TKP35H32-40W38R100
125	TKP35H32-30W38R125	TKP35H32-40W38R125
50	48	---	TKP35H32-30W50R48	---	---	TKP35H32-40W50R48	---	---	---	---
60	TKP35H32-30W50R60	TKP35H32-40W50R60
75	TKP35H32-30W50R75	TKP35H32-40W50R75
100	TKP35H32-30W50R100	TKP35H32-40W50R100
125	TKP35H32-30W50R125	TKP35H32-40W50R125

缆线软管最大外径30mm, 35mm (TKP58~，TKP62~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
30	62.5	34	150	75	---	---	---	---	---	---	---	TKP62H34W150R75	TKP62H34W150R75
90	TKP62H34W150R90	TKP62H34W150R90
125	TKP62H34W150R125	TKP62H34W150R125
150	TKP62H34W150R150	TKP62H34W150R150
200	TKP62H34W150R200	TKP62H34W150R200
200	75	---	---	---	---	---	---	---	TKP62H34W200R75	TKP62H34W200R75
90	TKP62H34W200R90	TKP62H34W200R90
125	TKP62H34W200R125	TKP62H34W200R125
150	TKP62H34W200R150	TKP62H34W200R150
200	TKP62H34W200R200	TKP62H34W200R200
35	58	39	50	60	---	TKP58H39-30W50R60	---	TKP58H39-30W50R60	TKP58H39-40W50R60	---	---	---	---
75	TKP58H39-30W50R75	TKP58H39-30W50R75	TKP58H39-40W50R75
90	TKP58H39-30W50R90	TKP58H39-30W50R90	TKP58H39-40W50R90
125	TKP58H39-30W50R125	TKP58H39-30W50R125	TKP58H39-40W50R125
150	TKP58H39-30W50R150	TKP58H39-30W50R150	TKP58H39-40W50R150
200	TKP58H39-30W50R200	TKP58H39-30W50R200	TKP58H39-40W50R200
75	60	---	TKP58H39-30W75R60	---	TKP58H39-30W75R60	TKP58H39-40W75R60	---	---	---	---
75	TKP58H39-30W75R75	TKP58H39-30W75R75	TKP58H39-40W75R75
90	TKP58H39-30W75R90	TKP58H39-30W75R90	TKP58H39-40W75R90
125	TKP58H39-30W75R125	TKP58H39-30W75R125	TKP58H39-40W75R125
150	TKP58H39-30W75R150	TKP58H39-30W75R150	TKP58H39-40W75R150
200	TKP58H39-30W75R200	TKP58H39-30W75R200	TKP58H39-40W75R200
100	60	---	TKP58H39-30W100R60	---	TKP58H39-30W100R60	TKP58H39-40W100R60	---	---	---	---
75	TKP58H39-30W100R75	TKP58H39-30W100R75	TKP58H39-40W100R75
90	TKP58H39-30W100R90	TKP58H39-30W100R90	TKP58H39-40W100R90
125	TKP58H39-30W100R125	TKP58H39-30W100R125	TKP58H39-40W100R125
150	TKP58H39-30W100R150	TKP58H39-30W100R150	TKP58H39-40W100R150
200	TKP58H39-30W100R200	TKP58H39-30W100R200	TKP58H39-40W100R200
125	60	---	TKP58H39-30W125R60	---	TKP58H39-30W125R60	TKP58H39-40W125R60	---	---	---	---
75	TKP58H39-30W125R75	TKP58H39-30W125R75	TKP58H39-40W125R75
90	TKP58H39-30W125R90	TKP58H39-30W125R90	TKP58H39-40W125R90
125	TKP58H39-30W125R125	TKP58H39-30W125R125	TKP58H39-40W125R125
150	TKP58H39-30W125R150	TKP58H39-30W125R150	TKP58H39-40W125R150
200	TKP58H39-30W125R200	TKP58H39-30W125R200	TKP58H39-40W125R200

缆线软管最大外径41mm, 45mm (TKP68~，TKP90~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
41	68	46	75	75	---	TKP68H46-30W75R75	---	TKP68H46-30W75R75	TKP68H46-40W75R75	---	---	---	---
100	TKP68H46-30W75R100	TKP68H46-30W75R100	TKP68H46-40W75R100
125	TKP68H46-30W75R125	TKP68H46-30W75R125	TKP68H46-40W75R125
150	TKP68H46-30W75R150	TKP68H46-30W75R150	TKP68H46-40W75R150
200	TKP68H46-30W75R200	TKP68H46-30W75R200	TKP68H46-40W75R200
250	TKP68H46-30W75R250	TKP68H46-30W75R250	TKP68H46-40W75R250
100	75	---	TKP68H46-30W100R75	---	TKP68H46-30W100R75	TKP68H46-40W100R75	---	---	---	---
100	TKP68H46-30W100R100	TKP68H46-30W100R100	TKP68H46-40W100R100
125	TKP68H46-30W100R125	TKP68H46-30W100R125	TKP68H46-40W100R125
150	TKP68H46-30W100R150	TKP68H46-30W100R150	TKP68H46-40W100R150
200	TKP68H46-30W100R200	TKP68H46-30W100R200	TKP68H46-40W100R200
250	TKP68H46-30W100R250	TKP68H46-30W100R250	TKP68H46-40W100R250
125	75	---	TKP68H46-30W125R75	---	TKP68H46-30W125R75	TKP68H46-40W125R75	---	---	---	---
100	TKP68H46-30W125R100	TKP68H46-30W125R100	TKP68H46-40W125R100
125	TKP68H46-30W125R125	TKP68H46-30W125R125	TKP68H46-40W125R125
150	TKP68H46-30W125R150	TKP68H46-30W125R150	TKP68H46-40W125R150
200	TKP68H46-30W125R200	TKP68H46-30W125R200	TKP68H46-40W125R200
250	TKP68H46-30W125R250	TKP68H46-30W125R250	TKP68H46-40W125R250
150	75	---	TKP68H46-30W150R75	---	TKP68H46-30W150R75	TKP68H46-40W150R75	---	---	---	---
100	TKP68H46-30W150R100	TKP68H46-30W150R100	TKP68H46-40W150R100
125	TKP68H46-30W150R125	TKP68H46-30W150R125	TKP68H46-40W150R125
150	TKP68H46-30W150R150	TKP68H46-30W150R150	TKP68H46-40W150R150
200	TKP68H46-30W150R200	TKP68H46-30W150R200	TKP68H46-40W150R200
250	TKP68H46-30W150R250	TKP68H46-30W150R250	TKP68H46-40W150R250
175	75	---	TKP68H46-30W175R75	---	TKP68H46-30W175R75	TKP68H46-40W175R75	---	---	---	---
100	TKP68H46-30W175R100	TKP68H46-30W175R100	TKP68H46-40W175R100
125	TKP68H46-30W175R125	TKP68H46-30W175R125	TKP68H46-40W175R125
150	TKP68H46-30W175R150	TKP68H46-30W175R150	TKP68H46-40W175R150
200	TKP68H46-30W175R200	TKP68H46-30W175R200	TKP68H46-40W175R200
250	TKP68H46-30W175R250	TKP68H46-30W175R250	TKP68H46-40W175R250
45	90	50	100	130	---	---	---	---	---	---	---	TKP90H50W100R130	TKP90H50W100R130
200	TKP90H50W100R200	TKP90H50W100R200
250	TKP90H50W100R250	TKP90H50W100R250
300	TKP90H50W100R300	---
150	130	---	---	---	---	---	---	---	TKP90H50W150R130	TKP90H50W150R130
200	TKP90H50W150R200	TKP90H50W150R200
250	TKP90H50W150R250	TKP90H50W150R250
300	TKP90H50W150R300	---
200	130	---	---	---	---	---	---	---	TKP90H50W200R130	TKP90H50W200R130
200	TKP90H50W200R200	TKP90H50W200R200
250	TKP90H50W200R250	TKP90H50W200R250
300	TKP90H50W200R300	---

缆线软管最大外径50mm (TKP91H56~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
50	91	56	150	150	---	---	---	---	---	---	---	TKP91H56W150R150	---
200	TKP91H56W150R200	TKP91H56W150R200-GA
250	TKP91H56W150R250	TKP91H56W150R250-GA
300	TKP91H56W150R300	TKP91H56W150R300-GA
350	TKP91H56W150R350	---
400	TKP91H56W150R400	---
175	150	---	---	---	---	---	---	---	TKP91H56W175R150	---
200	TKP91H56W175R200	TKP91H56W175R200-GA
250	TKP91H56W175R250	TKP91H56W175R250-GA
300	TKP91H56W175R300	TKP91H56W175R300-GA
350	TKP91H56W175R350	---
400	TKP91H56W175R400	---
200	150	---	---	---	---	---	---	---	TKP91H56W200R150	---
200	TKP91H56W200R200	TKP91H56W200R200-GA
250	TKP91H56W200R250	TKP91H56W200R250-GA
300	TKP91H56W200R300	TKP91H56W200R300-GA
350	TKP91H56W200R350	---
400	TKP91H56W200R400	---
225	150	---	---	---	---	---	---	---	TKP91H56W225R150	---
200	TKP91H56W225R200	TKP91H56W225R200-GA
250	TKP91H56W225R250	TKP91H56W225R250-GA
300	TKP91H56W225R300	TKP91H56W225R300-GA
350	TKP91H56W225R350	---
400	TKP91H56W225R400	---
250	150	---	---	---	---	---	---	---	TKP91H56W250R150	---
200	TKP91H56W250R200	TKP91H56W250R200-GA
250	TKP91H56W250R250	TKP91H56W250R250-GA
300	TKP91H56W250R300	TKP91H56W250R300-GA
350	TKP91H56W250R350	---
400	TKP91H56W250R400	---
275	150	---	---	---	---	---	---	---	TKP91H56W275R150	---
200	TKP91H56W275R200	TKP91H56W275R200-GA
250	TKP91H56W275R250	TKP91H56W275R250-GA
300	TKP91H56W275R300	TKP91H56W275R300-GA
350	TKP91H56W275R350	---
400	TKP91H56W275R400	---
300	150	---	---	---	---	---	---	---	TKP91H56W300R150	---
200	TKP91H56W300R200	TKP91H56W300R200-GA
250	TKP91H56W300R250	TKP91H56W300R250-GA
300	TKP91H56W300R300	TKP91H56W300R300-GA
350	TKP91H56W300R350	---
400	TKP91H56W300R400	---
325	150	---	---	---	---	---	---	---	TKP91H56W325R150	---
200	TKP91H56W325R200	TKP91H56W325R200-GA
250	TKP91H56W325R250	TKP91H56W325R250-GA
300	TKP91H56W325R300	TKP91H56W325R300-GA
350	TKP91H56W325R350	---
400	TKP91H56W325R400	---
350	150	---	---	---	---	---	---	---	TKP91H56W350R150	---
200	TKP91H56W350R200	TKP91H56W350R200-GA
250	TKP91H56W350R250	TKP91H56W350R250-GA
300	TKP91H56W350R300	TKP91H56W350R300-GA
350	TKP91H56W350R350	---
400	TKP91H56W350R400	---
400	150	---	---	---	---	---	---	---	TKP91H56W400R150	---
200	TKP91H56W400R200	TKP91H56W400R200-GA
250	TKP91H56W400R250	TKP91H56W400R250-GA
300	TKP91H56W400R300	TKP91H56W400R300-GA
350	TKP91H56W400R350	---
400	TKP91H56W400R400	---
450	150	---	---	---	---	---	---	---	TKP91H56W450R150	---
200	TKP91H56W450R200	TKP91H56W450R200-GA
250	TKP91H56W450R250	TKP91H56W450R250-GA
300	TKP91H56W450R300	TKP91H56W450R300-GA
350	TKP91H56W450R350	---
400	TKP91H56W450R400	---
500	150	---	---	---	---	---	---	---	TKP91H56W500R150	---
200	TKP91H56W500R200	TKP91H56W500R200-GA
250	TKP91H56W500R250	TKP91H56W500R250-GA
300	TKP91H56W500R300	TKP91H56W500R300-GA
350	TKP91H56W500R350	---
400	TKP91H56W500R400	---

缆线软管最大外径67mm (TKP125~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
67	125	74	150	185	---	---	---	---	---	---	---	TKP125H74W150R185	TKP125H74W150R185
250	TKP125H74W150R250	TKP125H74W150R250
350	TKP125H74W150R350	TKP125H74W150R350
450	TKP125H74W150R450	---
250	185	---	---	---	---	---	---	---	TKP125H74W250R185	TKP125H74W250R185
250	TKP125H74W250R250	TKP125H74W250R250
350	TKP125H74W250R350	TKP125H74W250R350
450	TKP125H74W250R450	---
350	185	---	---	---	---	---	---	---	TKP125H74W350R185	TKP125H74W350R185
250	TKP125H74W350R250	TKP125H74W350R250
350	TKP125H74W350R350	TKP125H74W350R350
450	TKP125H74W350R450	---

缆线软管最大外径72mm (TKP91H80~)

缆线・软管最大外径 mm	间距 mm	内高 mm	内宽 mm	弯曲半径 mm	盖板开闭构造
					一体式	盖板外周侧开闭类型			盖板内周侧开闭类型			盖板内外周侧开闭类型
					一体式	标准规格	MW规格	长跨距规格	标准规格	MW规格	长跨距规格	标准规格	长跨距规格
4	13	10	6	20	TKP13H10-20W6R20	TKP13H10-30W6R20	---	---	---	---	---	---	---
				28	TKP13H10-20W6R28	TKP13H10-30W6R28
				37	TKP13H10-20W6R37	TKP13H10-30W6R37
7	17	11	10	17	---	TKP17H11-30W10R17	---	---	---	---	---	---	---
8	13	10	10	18	---	TKP13H10-30W10R18TC	TKP13H10-30W10R18M	---	---	---	---	---	---
				20	TKP13H10-20W10R20	---	---
				28	TKP13H10-20W10R28	TKP13H10-30W10R28TC	TKP13H10-30W10R28M
				37	TKP13H10-20W10R37	TKP13H10-30W10R37TC	TKP13H10-30W10R37M
			15	20	TKP13H10-20W15R20	TKP13H10-30W15R20	---	---	---	---	---	---	---
				28	TKP13H10-20W15R28	TKP13H10-30W15R28
				37	TKP13H10-20W15R37	TKP13H10-30W15R37
			20	18	---	TKP13H10-30W20R18TC	TKP13H10-30W20R18M	---	---	---	---	---	---
				20	TKP13H10-20W20R20	---	---
				28	TKP13H10-20W20R28	TKP13H10-30W20R28TC	TKP13H10-30W20R28M
				37	TKP13H10-20W20R37	TKP13H10-30W20R37TC	TKP13H10-30W20R37M

椿本产业机械产品 信息网站

塑料系列 桥式TKP型、TKP型MW规格、TKP型长跨距规格、TKP型旋转规格

特性

TKP型

TKP型MW规格

特殊规格

TKP型长跨距规格

TKP型旋转规格

产品目录、使用说明书

商品一览表

椿本产业机械产品信息网站

塑料系列桥式TKP型、TKP型MW规格、TKP型长跨距规格、TKP型旋转规格
